Which SSD Gets the Best Notebook Battery Life?

When we take into account the components that affect the battery life of the laptop, the CPU and the display panel will get the highest charge. However, the storage drive also uses a lot of energy, and with the right power supply can significantly improve the durability of the laptop. Our sister website, Tom hardware, has just released more than 100 detailed analysis of battery life of different solid state drives and hard drives, and the results may surprise you.

Test Conditions

All of the storage drives were tested in a Lenovo IdeaPad Y700-17ISK with a Core i7-6700HQ CPU and 16GB of RAM. This slightly-older laptop has room for both a standard, SATA drive and a slim, PCIe-NVMe SSD, so it was able to accommodate all 108 drives they tested. It’s not a particularly long-lasting laptop as its Lenovo Ideapad y550 Battery life ranged from 392 minutes (6:32 hours) on the most power efficient drive to 258 minutes (4:18 hours) on the worst. Tom’s Hardware used the MobileMark 2014 battery test, which runs a variety of applications, but doesn’t download any data from the Internet.

SSD vs Hard Drive

Because SSDs have no moving parts, you might expect that they would always use less power than mechanical hard drives. While most hard drives gulp more juice than their solid-state counterparts, there are some exceptions. Seven different hard drives allowed the laptop to last over 5 hours on a charge, while 13 of the 41 NVMe SSDs and 4 of the 58 SATA SSDs they tested fell below that mark. The most power efficient hard drive, the Seagate Momentus Thin (500GB) provided 331 minutes of battery life, which is more endurance than 7 of the NVMe SSDs and 10 of the SATA SSDs.

Overall, the average hard drive provided 5 hours and 16 minutes of battery life and the average NVMe PCIe SSD was actually a minute behind that. The mean time for a SATA SSD was a much-stronger 5 hours and 48 minutes.

SATA SSDs vs PCIe-NVMe SSDs

While more laptops still use SSDs that connect via the SATA (Serial ATA) interface, an increasing number now use the PCIe-NVMe interface, which offers speeds that can be two to five times faster. However, with this added performance there’s usually less power efficiency. According to Tom’s Hardware’s tests, the average PCIe-NVMe SSD lasted 33 minutes less on a charge. However, the longest-lasting NVMe-PCIe drive, the Samsung SM951 (256GB) endured for 6 hours and 24 minutes, which is only 10 minutes less than the best SATA drive, the SanDisk Z410 (6:34).

Overall, these were the most power-efficient SSDs, including both SATA and PCIe-NVMe models.

Winners and Bottom Line

The longest-lasting SSD Tom’s Hardware tested overall, which is a SATA model, is the SanDisk Z410 480GB (6:34) while the best PCIe-NVMe SSD is the Samsung SM951 256GB (6:24). However, when you’re purchasing a brand new laptop, you don’t have any choice about the make and model of SSD. Most manufacturers only disclose the SSD capacity and whether it’s PCIe-NVMe or SATA.
